Stroke: 8 inches

Rated Max. Brake HP: 2250BHP (1,641KW)

Maxim Rod Load: 225,000lbs

Gear Ratio: 6.353:1

Pump Weight: 12,680lbs approx.

Equivalent to GD/SPM/JMAC/SJS QWS1000

Application: Fracturing.

Quintuplex Pump is a multi-cylinder pump with excellent performance, playing an important role in many industrial fields.

1. Structural features

Five-cylinder design

The five-cylinder structure of Quintuplex Pump is its core feature. This structure makes the power output of the pump more uniform and stable during operation. Compared with pumps with other cylinder numbers, the coordinated work of five cylinders can effectively reduce the pulsation of the flow. For example, during the fluid delivery process, it can avoid problems such as pipeline vibration caused by flow fluctuations, ensuring the smooth operation of the entire fluid delivery system.

Precision manufacturing

Each cylinder and internal components are precision machined. The inner wall of the cylinder is smooth, and the degree of fit between the piston and the cylinder is extremely high, which can not only ensure good sealing and prevent fluid leakage, but also reduce friction loss during piston movement, thereby extending the service life of the components.

2. Performance advantages

High efficiency

The pump has a high flow and pressure output capacity. Whether it is transporting high-viscosity crude oil and chemical raw materials in the petrochemical industry, or transporting building materials such as concrete in the construction industry, Quintuplex Pump can complete the task in an efficient way. It can deliver a large amount of fluid in a short time and improve work efficiency.

Reliability

Due to the use of durable materials and advanced manufacturing processes, Quintuplex Pump can operate stably in harsh working environments. Whether it is a high temperature, high pressure or highly corrosive environment, such as in an offshore oil extraction platform or a highly corrosive environment in chemical production, it can maintain a good working condition and reduce downtime and losses caused by equipment failure.

3. Wide Application

Petroleum Industry

In the process of oil extraction, Quintuplex Pump can be used for water injection, oil extraction and long-distance transportation of oil in oil wells. Its stable performance helps to maintain the normal production of oil wells and improve the efficiency and safety of oil extraction.

Construction Engineering

On construction sites, it can be used for concrete pumping operations. With its strong conveying capacity and stable flow output, it can quickly and accurately deliver concrete to the required location, such as in the construction of high-rise buildings, greatly improving the efficiency of construction.

Quintuplex Pump has become an indispensable fluid conveying equipment in many industrial fields with its unique structure, excellent performance and wide adaptability.
