Maximum Input: 2,250 BHP(1, 865 kw)

Maximum RPM: 330 RPM

Max. Rod Load: 225,000 lbs, (102,060 kg)

Stroke Length: 8"(203 mm)

Pump Weight: 12,650 lbs. (5,738 kg)

Gear Ratio: 6.353:1

Approx. Length: 89.9" (2,285 mm)

Approx. Width: 59.8" (1,520 mm)

Approx. Height: 44.4" (1, 128 mm)

Approx. Weight: 11,755 lbs. (5,340 kg)

Application: Fracturing.

The TWS2250 Triplex Pump is a three-cylinder pump that excels in industrial and specific applications.

1. Excellent performance

Powerful power

This pump adopts advanced design concepts and has powerful output power. It can operate stably under various complex working conditions. Whether it is a scene with high pressure or large flow demand, TWS2250 can handle it with ease. Its maximum pressure can reach [X]MPa, and the flow rate can meet the requirements of [specific flow range], which makes it play an important role in fields such as high-pressure grouting in construction projects and fluid transportation in oil production.

Efficient operation

The internal structure of the pump has been carefully optimized to reduce energy loss. The three-cylinder structure ensures the continuity and stability of fluid transportation and reduces pulsation. This efficient operation feature not only improves work efficiency, but also reduces energy consumption in long-term use, saving costs for users.

2. Reliable quality

High-quality materials

TWS2250 is made of high-strength, corrosion-resistant materials. The pump body is made of high-quality metal alloy, which can resist the erosion of various chemicals and adapt to different working environments. Key components such as pistons and seals are also made of wear-resistant and high-temperature resistant materials, which greatly extends the service life of the pump.

Precision manufacturing

It follows strict process standards during the manufacturing process, and the processing accuracy of each component is extremely high. This ensures good coordination between components and reduces the probability of failure. The overall structure of the pump is compact and easy to install and maintain.

3. Multifunctional application

Wide industry adaptability

Due to its excellent performance and reliable quality, TWS2250 Triplex Pump is widely used in many industries. In the construction industry, it can be used for concrete delivery and foundation reinforcement grouting; in the chemical industry, it can be used to transport various chemical raw materials; in the mining industry, it can be used for mine drainage and slurry delivery. It is a multifunctional three-cylinder pump that can meet the needs of different industries.
